| Ürün Kodu |
Ürün Açıklaması |
Ölçüler (mm) |
Hatve |
Pullar Arası Genişlik |
Makara Çapı |
Pim Çapı |
|
Genişlik |
Gerilme Kuv. |
İndirilebilir |
|
|
|
P |
W |
D |
d |
E |
C |
N |
Dosyalar |
| ORK ZB 06B1 |
ZİNCİR BAKLASI TEK SIRA 06B*1 (3/8″*1) |
3/8”x 7/32” |
9,525 |
5,72 |
6,35 |
3,28 |
|
13,15 |
9000 |
|
| ORK ZB 08B1 |
ZİNCİR BAKLASI TEK SIRA 08B*1 (1/2″*1) |
1/2”x 5/16” |
12,700 |
7,75 |
8,51 |
4,45 |
|
16,70 |
18000 |
|
| ORK ZB 10B1 |
ZİNCİR BAKLASI TEK SIRA 10B*1 (5/8″*1) |
5/8” |
15,875 |
9,65 |
10,16 |
5,08 |
|
19,50 |
22400 |
|
| ORK ZB 12B1 |
ZİNCİR BAKLASI TEK SIRA 12B*1 (3/4″*1) |
3/4” |
19,050 |
11,68 |
12,07 |
5,72 |
|
22,50 |
29000 |
|
| ORK ZB 16B1 |
ZİNCİR BAKLASI TEK SIRA 16B*1 (1″*1) |
1” |
25,400 |
17,02 |
15,88 |
8,28 |
|
36,10 |
60000 |
|
| ORK ZB 20B1 |
ZİNCİR BAKLASI TEK SIRA 20B*1 (1″1/4*1) |
1”1/4 |
31,750 |
19,56 |
19,05 |
10,19 |
|
41,30 |
95000 |
|
| ORK ZB 24B1 |
ZİNCİR BAKLASI TEK SIRA 24B*1 (1″1/2*1) |
1”1/2 |
38,100 |
25,40 |
25,40 |
14,63 |
|
53,40 |
160000 |
|
| ORK ZB 32B1 |
ZİNCİR BAKLASI TEK SIRA 32B*1 (2″*1) |
2” |
50,800 |
30,99 |
29,21 |
17,81 |
|
66,00 |
250000 |
|
| ORK ZB 06B2 |
ZİNCİR BAKLASI ÇİFT SIRA 06B*2 (3/8″*2) |
3/8”x 7/32” |
9,525 |
5,72 |
6,35 |
3,28 |
10,24 |
23,40 |
16900 |
|
| ORK ZB 08B2 |
ZİNCİR BAKLASI ÇİFT SIRA 08B*2 (1/2″*2) |
1/2”x 5/16” |
12,700 |
7,75 |
8,51 |
4,45 |
13,92 |
31,20 |
32000 |
|
| ORK ZB 10B2 |
ZİNCİR BAKLASI ÇİFT SIRA 10B*2 (5/8″*2) |
5/8” |
15,875 |
9,65 |
10,16 |
5,08 |
16,59 |
36,10 |
44500 |
|
| ORK ZB 12B2 |
ZİNCİR BAKLASI ÇİFT SIRA 12B*2 (3/4″*2) |
3/4” |
19,050 |
11,68 |
12,07 |
5,72 |
19,46 |
42,00 |
57800 |
|
| ORK ZB 16B2 |
ZİNCİR BAKLASI ÇİFT SIRA 16B*2 (1″*2) |
1” |
25,400 |
17,02 |
15,88 |
8,28 |
31,88 |
68,00 |
106000 |
|
| ORK ZB 20B2 |
ZİNCİR BAKLASI ÇİFT SIRA 20B*2 (1″1/4*2) |
1”1/4 |
31,750 |
19,56 |
19,05 |
10,19 |
36,45 |
77,80 |
170000 |
|
| ORK ZB 24B2 |
ZİNCİR BAKLASI ÇİFT SIRA 24B*2 (1″1/2*2) |
1”1/2 |
38,100 |
25,40 |
25,40 |
14,63 |
48,36 |
101,70 |
280000 |
|
| ORK ZB 32B2 |
ZİNCİR BAKLASI ÇİFT SIRA 32B*2 (2″*2) |
2” |
50,800 |
30,99 |
29,21 |
17,81 |
58,55 |
124,60 |
450000 |
|
